FPP53WC250SWR2R0N
22222222
| Quantity: | |
|---|---|
Galvanized sheet steel housing,screwing by plate with hole pattern 105 x 84/76mm,housing with material strength 3.0mm (fitting) and 3.0mm (fork),clearance between the fork 60mm,wheel rim made of sheet steel blue passivated with a tread made of solid rubber 85°shore A grey,hub width 59mm,central roller bearing,screwed wheel axle(incl. all axle material).
| Wheel diameter: | 250 mm |
| Wheel width: | 50 mm |
| Mounting plate: | 135 x 110 mm |
| Mounting hole dimension: | 105 x 84/76 mm |
| Hole diameter: | 11 mm |
| Plate thickness: | 3.0 mm |
| Fork thickness: | 3.0 mm |
| Axle bolt: | 12 mm |
| Hub width: | 59 mm |
| Total height: | 295 mm |
| Wheel center: | sheet steel blue passivated |
| Wheel tread: | solid rubber(85°shore A) grey |
| Wheel bearing: | roller bearing |
| Thread guard: | without threadguard |
| Temperature range: | -20°C to + 60°C |
| DIN EN Norm: | DIN EN 12532 |
| Load capacity: | 250 kg |
| Unit weight: |
Galvanized sheet steel housing,screwing by plate with hole pattern 105 x 84/76mm,housing with material strength 3.0mm (fitting) and 3.0mm (fork),clearance between the fork 60mm,wheel rim made of sheet steel blue passivated with a tread made of solid rubber 85°shore A grey,hub width 59mm,central roller bearing,screwed wheel axle(incl. all axle material).
| Wheel diameter: | 250 mm |
| Wheel width: | 50 mm |
| Mounting plate: | 135 x 110 mm |
| Mounting hole dimension: | 105 x 84/76 mm |
| Hole diameter: | 11 mm |
| Plate thickness: | 3.0 mm |
| Fork thickness: | 3.0 mm |
| Axle bolt: | 12 mm |
| Hub width: | 59 mm |
| Total height: | 295 mm |
| Wheel center: | sheet steel blue passivated |
| Wheel tread: | solid rubber(85°shore A) grey |
| Wheel bearing: | roller bearing |
| Thread guard: | without threadguard |
| Temperature range: | -20°C to + 60°C |
| DIN EN Norm: | DIN EN 12532 |
| Load capacity: | 250 kg |
| Unit weight: |
